standard wheel + elastic rubber tyre Ø200 x W50mm for 400kg Prod ID: 40153

Brand: LIV SYSTEMS

Product description
Deep draw press forming and surface treatment of OE steel parts is our expertise

standard Wheel with ball bearing and elastic rubber tyre with hardness 70 ° shore A on polyamide
Wheel diameter x width: 200 x 50 mm
Axle hole: 20 mm
Hub length: 58 mm

Approved and tested load capacity
Dynamic 400 kg
Static 500 kg

Temperature range:
Continious operation: -25 | +80°C
Short (10 min) exposure: -30 | +110°C

Advantages of this Soft floor wheel wheel:
✓ force to start
✓ ride
✓ to surface when stationed

Deep draw press forming and surface treatment of OE steel parts is our expertise

LIV SYSTEMS standard wheel + elastic rubber tyre Ø200 x W50mm for 400kg Prod ID: 40153

ID 40153:standard Wheel with ball bearing and elastic rubber tyre with hardness 70 ° shore A on polyamide | Axle hole: 20 mm | Hub length: 58 mm | Soft floor wheel, low force to start, smooth ride, gentle to surface when stationed
