Wheel 125 mm, heat-resistant polyamide, plain bearing, axle hole 12 mm, 200 kg, product code 44909
Wheel with heat-resistant solid polyamide wheel, wheel diameter 125 mm, on plain bearing. It carries 200 kg dynamic and 250 kg static, with a 12 mm axle hole.
- Looking for a castor or wheel for your application? Contact us.
- Ask us for CAD models in STEP and IGES formats
- Short delivery times for large quantities of castors
- Pressing steel OEM parts is our expertise
You are in our product catalogue. This opens livsystems.eu in a new tab, where we show our factory and the background of the company.
Product description
| Type | Wheel |
|---|---|
| Wheel diameter | 125 mm |
| Wheel width | 38 mm |
| Tread | heat-resistant solid polyamide wheel, 85±5 Shore D |
| Wheel centre | heat-resistant polyamide |
| Bearing | plain bearing |
| Load capacity, dynamic | 200 kg |
| Load capacity, static | 250 kg |
| Axle hole | 12 mm |
| Weight | 0.27 kg |
| Temperature, continuous | -25 to +250 °C |
| Temperature, short exposure (max. 10 min) | -40 to +300 °C |
| Fitting | Wheel hub |
| Hub length | 45 mm |
| Tread material | Heat resistant polyamide |
| Tread hardness | 85 Shore D |
Properties and use
Built for heat and used in bakeries. The continuous and short-term temperatures are in the table. On request: other wheel and tyre colours, and an electrically conductive or antistatic tyre (ESD).
Send us the drawing or the dimensions of the castor you are replacing and we confirm the match. Quote within 1 to 2 working days.
Specifications from the LIV product database, October 2026.
Product information
| Product code | 44909 |
|---|---|
| Drawing number | 2-762 ISO |
| EAN | 3838461449093 |
Made by LIV
About LIV as a manufacturer of castors and wheels (opens in a new tab)
Need a version to your drawing? Project inquiry (opens in a new tab)
