| Type | Furniture swivel castor |
|---|---|
| Wheel diameter | 50 mm |
| Wheel width | 17.5 mm |
| Tread | solid polyamide wheel, 70±5 Shore D |
| Wheel centre | polyamide |
| Bearing | plain bearing |
| Load capacity, dynamic | 80 kg |
| Load capacity, static | 100 kg |
| Fitting | single bolt hole |
| Hole diameter | 10.5 mm |
| Overall height | 72 mm |
| Offset | 32 mm |
| Weight | 0.22 kg |
| Temperature, continuous | -25 to +80 °C |
| Temperature, short exposure (max. 10 min) | -30 to +110 °C |
Fork zinc electroplated and Cr(VI)-free.
Properties and use
Plain design that turns on the spot easily. An economical choice. On request: other wheel and tyre colours, and an electrically conductive or antistatic tyre (ESD).
Send us the drawing or the dimensions of the castor you are replacing and we confirm the match. Quote within 24 hours.
Specifications from the LIV product database, October 2026.
