heat resistant wheel + solid heat resistant polyamide wheel Ø80 x W35mm for 150kg Prod ID: 44906

Brand: LIV SYSTEMS

Product description
Deep draw press forming and surface treatment of OE steel parts is our expertise

Heat resistant Wheel with plain bearing and solid heat resistant polyamide wheel with hardness 85±5 ° Shore D.
Wheel diameter x width: 80 x 35 mm
Axle hole: 12 mm
Hub length: 45 mm

Approved and tested load capacity:
Dynamic: 150 kg
Static: 180 kg

Temperature range:
Continious operation: -25 | +250°C
Short (10 min) exposure: -40 | +300°C

Advantages of rotation of heat resistant wheel at higher temeratures:
✓ to 300°C
✓ for bakeries
✓ material endurance

Deep draw press forming and surface treatment of OE steel parts is our expertise

LIV SYSTEMS heat resistant wheel + solid heat resistant polyamide wheel Ø80 x W35mm for 150kg Prod ID: 44906

ID 44906:heat resistant Wheel with plain bearing and solid heat resistant polyamide wheel with hardness 85±5 ° Shore D | Axle hole: 12 mm | Hub length: 45 mm | Roll into hot destination, up to 300°C, ideal for bakeries, high material endurance

Quantity

You need Innovative & durable wheel solutions? contact us Tooltip The result of our quality is maximum performance!
Ask us for CAD/STEP/Iges Models
Fastest delivery of high quantities of castors possible
Press forming steel OEM parts is our expetise
