Stainless steel wheel 160 mm, polyurethane, ball bearing, axle hole 20 mm, 400 kg, product code 42294

Stainless steel wheel with a 160 mm wheel, polyurethane tread, on ball bearing. It carries 400 kg dynamic and 500 kg static, with a 20 mm axle hole.

  • Looking for a castor or wheel for your application? Contact us.
  • Ask us for CAD models in STEP and IGES formats
  • Short delivery times for large quantities of castors
  • Pressing steel OEM parts is our expertise
Download PDF See our factory (opens in a new tab)

You are in our product catalogue. This opens livsystems.eu in a new tab, where we show our factory and the background of the company.

Product description

TypeStainless steel wheel
Wheel diameter160 mm
Wheel width50 mm
Treadpolyurethane tread, 92 Shore A
Tread colourgreen
Wheel centrepolyamide
Bearingball bearing
Load capacity, dynamic400 kg
Load capacity, static500 kg
Axle hole20 mm
Weight0.65 kg
Temperature, continuous-25 to +55 °C
Temperature, short exposure (max. 10 min)-30 to +55 °C
FittingWheel hub
Hub length58 mm
Tread materialInjection-moulded polyurethane

Properties and use

Little deformation when the unit stands still, and oil resistant. The temperature range is wide, see the table. On request: other wheel and tyre colours, and an electrically conductive or antistatic tyre (ESD).

Send us the drawing or the dimensions of the castor you are replacing and we confirm the match. Quote within 1 to 2 working days.

Specifications from the LIV product database, October 2026.
