stainless steel wheel + elastic rubber tyre Ø100 x W35mm for 150kg Prod ID: 42144

Product description

stainless steel Wheel with ball bearing and elastic rubber tyre with hardness 70 ° Shore A on polyamide
Wheel diameter x width: 100 x 35 mm
Axle hole: 12 mm
Hub length: 44 mm

Approved and tested load capacity
Dynamic 150 kg
Static 180 kg

Temperature range:
Continious operation: -25 | +80°C
Short (10 min) exposure: -30 | +110°C



Advantages of this Tile floor ride wheel:
✓ absorbing
✓ ride over obstacles
✓ to keep clean

Deep draw press forming and surface treatment of OE steel parts is our expertise

Deep draw press forming and surface treatment of OE steel parts is our expertise

LIV SYSTEMS stainless steel wheel + elastic rubber tyre Ø100 x W35mm for 150kg Prod ID: 42144

ID 42144:stainless steel Wheel with ball bearing and elastic rubber tyre with hardness 70 ° Shore A on polyamide | Axle hole: 12 mm | Hub length: 44 mm | Tile floor ride, shock absorbing, smooth ride over obstacles, easy to keep clean

Enter the number of articles below and click

Ok

  • You need Innovative & durable wheel solutions? contact us Tooltip The result of our quality is maximum performance!
  • Ask us for CAD/STEP/Iges Models
  • Fastest delivery of high quantities of castors possible
  • Press forming steel OEM parts is our expetise

Request OE parts

Download PDF

Product information

  • Article code 2-040-20K
  • SKU 42144
  • EAN 3838461421440

Specifications
